Eunorau FAT-STEP 48V500W 20'' Fat Tire Folding Step-Thru Electric Bike

INVENTORY NOTE:

Pink and Cream IN STOCK. Other colours will take 5-10 days to bring in from the main warehouse. Please be advised of the short wait when ordering these other colours.

DESCRIPTION:

The Eunorau FAT-STEP bike is a compact but powerful electric bike ready to zip you away on your adventures. Able to fold down to a size that fits most trunks and hatchbacks, the FAT-STEP provides a convenient way to transport or store it. Built with a powerful 500W rear-hub motor and high-capacity 12.5Ah battery, the FAT-STEP is a reliable trekker whether on a trail or street. Add to that, a 7-speed Shimano drive train, and you’ll be climbing hills or cruising along on pedal-assist. The ample treads of the Kenda 4-inch fat tires take on snow, mud and off-road trekking. While the step-through frame design makes it easy to mount and dismount.

Eunorau, established in 2010, has over a decade of electric bike manufacturing experience. As the name suggests (EU-NOR-AU), has a strong distributer network across Europe, North America and Australia. They are known for premium quality e-bikes and e-bike conversion kits, but especially their line of fat tire e-bikes. Phoenix Fitness is an authorized dealer of Eunorau products in Canada.

KEY FEATURES:

  • REAR-MOTOR, HIGH-CAPACITY BATTERY: Driving the FAT-STEP is the Shengyi 500W rear-hub motor with 750W of peak power, 80Nm of torque and a max speed of 32 km/h. A high-capacity 12.5Ah battery gives you good range to take you exploring. The locking removable battery located beneath the bike’s saddle, not only keeps the center of gravity low and overall weight well-balanced but makes it convenient to charge.
  • FAT TIRE TRACTION:  20" * 4.0" Kenda Krusade Sport tires have a deep, spacious tread great for grabbing, draining and discharging loose terrain. These fat tires adapt expertly to snow, sand, mountain trails and cross-country trekking.
  • FOLDING FRAME: Having a folding system within the main frame tube and telescoping stem is great feature for transporting and storing your bike. The step-thru design makes mounting and dismounting an ease.
  • SHIFTING: With this Shimano 7-speed freewheel, a large cog benefits up-hill riding, while a smaller cog is best for high-speed riding. Speed can be easily adjusted with the pedal-assist system.
  • RELIABILITY: Promax disc brakes require less effort to stop a bike and generate less heat. Disc brakes are easy to control and provide reliable stopping power in wet and dry conditions. Integrated with a motor cut-off sensor, braking is smooth and controlled.
  • SUGGESTED RIDER HEIGHT: 167 cm – 185 cm (5’6” – 6’1”)



FAT-STEP

SPECIFICATIONS

SYSTEM

MOTOR

Rear Shengyi 48V/500W brushless hub motor (high torque)

BATTERY

Lithium-ion, 48V/12.5Ah

CHARGER

2.0A Smart Charger (US/Canadian Standard)

DISPLAY

K-LCD5 Panel

CONTROLLER

48V/20A

PEDAL ASSIST

Intelligent: 0-5 levels of pedal assist

LIGHTS

Front LED lamp / Rear LED taillight

THROTTLE

Thumb throttle

FRAME

FRAME

Aluminum Alloy 6061

DRIVETRAIN

FREEWHEEL

Shimano Derailleur 7-speed gear shift system

GEARING

Shimano 7-speed 1*7 ATLUS

SHIFTERS

Shimano 7-speed Push-Button

SPROCKET

48T chain-wheel crank with guard

CRANK

170mm forged aluminum alloy

COMPONENTS

BRAKES

Front/Rear Promax 160mm Disc Brakes

BRAKE LEVERS

Promax Disc Brakes Lever with motor cut-off switch

SEATPOST

Promax aluminum alloy

COCKPIT

HANDLEBAR

Adjustable stem (matte black)

STEM

Telescoping, 260mm base with 140mm extension, 10mm spacer, 25.4mm clamp diameter

SADDLE

Comfortable saddle

PEDALS

High-Quality folding Nylon pedals

WHEELS/TIRES

RIMS

Black 20” alloy

TIRES

Kenda Krusade Sport Tires 20” * 4.0”

PARAMETERS

MAX. RANGE

72 km/charge on a single motor

CHARGING TIME

4-6 Hours

MAX. SPEED

32 km/h (20 mph)

MAX. LOAD

150 kg (330 lbs.)

BOX DIMENSIONS

L*W*H 980*480*720 mm

WEIGHT

Net 29 kg (64 lbs.)
